LATEST NEWS

Announcing the SISM! Fri, Sep 26, 2014
Announcing a new module from 4ms: Shifting Inverting Signal Mingler (SISM)
The SISM is a 4-channel voltage manipulator that can scale, invert, attenuate, shift (dc offset), mix, split, and slice your CV and audio signals.

A plethora of red and blue LEDs (14) show exactly what each channel and output jack is doing: red = negative voltage, blue = positive.

Each channel is independent and has an input jack, output jack, a knob for attenuating/inverting (Scale), and a knob for applying positive or negative DC offset (Shift).

Four jacks on the bottom combine the four channels in different ways. Mix is a straight mix of all four shifted inputs, Switched Mix is a mix of all channels that have nothing plugged into the OUT jack, Positive Slice is the sum of all output voltages greater than zero volts, and Negative Slice is the sum of all negative voltages.

By Shifting some channels positive and some negative, the + Slice and - Slice jacks can be used as sub-mix outputs. Also, by running a slow triangle wave into one channel, the remaining channels can be made to "dirty pan" between the Slice jacks: the signals are half-wave rectified as they span between both outputs.

Channels 1+2 and 3+4 are normalized together on the input jacks, which is handy for splitting a signal into two or more altered forms. Jumpers on the back allow you to disable this normalization.

Each channel also has a jumper to make the Scale knob unipolar (no inverting, attenuate only). This is useful for mixing audio instead of CV. A breakout header allows for padding of the signal (useful for fine-tuning a precise voltage such as 1V/oct).

The SISM is 12HP wide, and 22mm deep.
It consumes a maximum of 51mA on the +12V and 51mA on the -12V rail.

Retail price: $175

Ships October 27

Read more about the SISM...
Come visit us at KnobCon Fri, Sep 12, 2014

We'll be at Knobcon in Chicago, Sept 12-14. Come visit our table, demo our latest modules and preview up-coming releases. Our Modular Row cases will be stacked higher than ever!

4MS QCD Expander Sale Fri, Aug 15, 2014

Modular Row Octagon! Thu, Aug 14, 2014

Eight Modular Rows and eight 45 angle pieces = this:



>>>older news
